If the thickness of ship's hull exceeds 15 mm
then 'M' (the connecting part between
thruster tunnel and motor) can't be moved
sufficiently outwards.
Then make a bevel 'V' at the inside of the
ship's hull where required.
4 .4

Installation of housing

• Position the housing on the opening.
n
ote
The interior of the housing must not sit be-
yond the opening in the hull further than
15 mm ( 5 / ").
8
• Measure the dimension 'H' .
• Calculate the difference between 'H' and
dimension 'G' from the table.
i
mportant
The available height inside the housing,
after installation in the hull, is very impor-
tant!
If the height is less than required it is not
possible to fully retract the thruster .
Therefore make sure that the part to
be cut off is EXACTLY the calculated
and scribed difference 'H - G' .
32
020584.01
M
<15 mm (
BOW
Bow thruster
35 kgf / 55 kgf
60 kgf / 75 kgf / 95 kgf
125 kgf / 160 kgf
M
5 / ") >15 mm (
8
BOW
Max. 15 mm (
Tunnel tube diameter
[mm] [in]
ø150 6
ø185 7 5 /
16
ø250 10
vetus® Installation instructions Retractable Thrusters
V
5 / ")
8
5 / ")
8
H
G
[mm] [in]
180 7 1 /
16
210 8 1 /
4
275 10 13 /
16
