Initial Setup - Össur PROPRIO FOOT PSX01 Instrucciones De Uso

Ankle Alignment failed: if unsuccessful, LED Indicator Ring will flash yellow, showing process needs to be repeated.
Note: If heel height exceeds
must then change shoes to a heel height under
ANKLE ALIGNMENT WEARING PROSTHESIS
After changing shoes, the user can perform Ankle Alignment while wearing the prosthesis.
Note: The user should always perform User Ankle Alignment when changing shoes or going barefoot.
. The user should be seated.
. Ensure device is positioned flat, with both the heel and forefoot area on the ground.
. Ensure the device is fully-charged and turned ON.
. Initiate Ankle Alignment by quickly pressing the power button twice successively.
. Initiation confirmed: the device will beep once, and a single white LED will light up.
. Wait for the nd beep and lift the device from the ground to allow for ankle adaptation.
. Ankle Alignment will initiate as described above from step ( ).
Users are asked to skip the "Initial Set-Up" section. These instructions are for the practitioner only. The user
should not attempt these adjustments.
INITIAL SET UP
The device set-up consists four steps, described in the following sections. Perform the steps in the following order:
. Bench Alignment including Ankle Alignment
. Dynamic Alignment
. Auto-Adjustment
. Advanced Set-Up
After turning the device ON, two orange lights on the LED Indicator Ring will show initial set-up is required.
One orange light on the right side of the LED Indicator Ring shows Auto-Adjustment is required.
One orange light on the left side of the LED Indicator Ring shows Ankle Alignment is required.
After successfully performing these activities, the orange lights will turn off and disappear from the LED Indicator
Ring.
mm ( ") the device will emit an audio signal and not adjust to height. The user
mm ( ") and repeat the adjustment.
13
