Technical alarms 1: (display in information area)
Message
SYS ALM LMT ERR
MEAN ALM LMT ERR
DIA ALM LMT ERR
Technical alarms 2: (display in the area below the NIBP value)
Message
NIBP SELF TEST
ERR
NIBP COMM ERR
LOOSE CUFF
AIR LEAK
AIR PRESSURE
ERROR
WEAK SIGNAL
RANGE EXCEEDED Measuring range exceeds the
EXCESSIVE
MOTION
OVER PRESSURE
SIGNAL STURATED Excessive motion
PNEUMATIC LEAK
NIBP SYSTEM
FAILURE
CUFF TYPE ERR
NIBP TIME OUT
NIBP ILLEGALLY
RESET
MEASURE FAIL
Cause
Functional safety failure
Functional safety failure
Functional safety failure
Cause
Sensor or other hardware of
NIBP module is incorrect.
Communication with NIBP
module is failed.
Cuff is no properly wrapped
or no cuff exists.
Cuff, hose or connector is dama-
ged.
Stable pressure value is not avai-
lable. e.g. hoses are
tangled.
Cuff is too loose or patient pulse
is too weak.
specified upper limit.
Affected by arm motion, signal
noise is too large or pulse rate is
not regular.
Pressure has exceeded the
specified upper safety limit.
During pneumatic test, leak
is detected.
Operation of blood pressure
pump system is failed.
Cuff type does not comply
with the patient type.
Measuring time has exceeded
120 seconds (adult) or 90
seconds (neonatal).
Abnormal module reset
Problem happens when
measuring the curve. The system
cannot perform measurement,
analysis or calculation.
Alarm Level Remedy
HIGH Stop using alarming functions
of NIBP module and notify
HIGH
biomedical engineer or Our
HIGH
service staff.
Alarm Remedy
Level
HIGH Stop using measuring function of NIBP
module, notify biomedical engineer
or Our service staff.
HIGH If failure persists, stop using measuring
function of NIBP module, notify biome-
dical engineer or Our service staff.
LOW Properly wrap the cuff
LOW Check and replace the leaking parts,
if required, notify biomedical engineer
or Our service staff.
LOW Check if the hoses are tangled, if failure
persists, notify biomedical engineer
or Our service staff.
LOW Use other method to measure blood
pressure.
HIGH Reset NIBP module, if failure persists,
stop using measuring function of NIBP
module, notify biomedical engineer
or Our service staff.
LOW Make sure that the patient under
monitoring is motionless.
HIGH Measure again, if failure persists, stop
using measuring function of NIBP
module and notify biomedical engineer
or Our service staff.
LOW Stop the patient from moving.
LOW Check and replace the leaking parts,
if required, notify biomedical engineer
or Our service staff.
HIGH Stop using measuring function of NIBP
module, notify biomedical engineer or
Our service staff.
LOW Select appropriate cuff type
HIGH Measure again or use other measuring
method.
HIGH Reset again
HIGH Check the cuff. Make sure that the
patient under monitoring is motionless.
Measure again.
