Signal sources for ZSW7
Signal Meaning
ZSW7.0 1 = DYNEGMA: torque limited
ZSW7.1 1 = Motor overtemperature: current reduction active
ZSW7.2 1 = Motor overtemperature: motor temperature model alarm active
ZSW7.3 1 = Pole position identification with encoder successfully carried out
ZSW7.4 1 = CHATDTEC: Chatter detected
ZSW7.5 1 = Motor overtemperature: motor temperature measurement alarm active
ZSW7.6 1 = AND logic operation: condition fulfilled
ZSW7.7 1 = OR logic operation: condition fulfilled
ZSW7.8 1 = Encoder maintenance required
ZSW7.9 Reserved
ZSW7.10 Reserved
ZSW7.11 Reserved
ZSW7.12 Reserved
ZSW7.13 Reserved
ZSW7.14 Reserved
ZSW7.15 Reserved
<1> Used in telegram 146, 148, 149.
<2> Only if Technology Extension "DYNEGMA" is active.
1 2
DO: SERVO
PROFIdrive - ZSW7 status word interconnection
Interconnection
parameters
<2> p2083[0] = r32605.2
p2083[1] = r5389.8
p2083[2] = r5389.5
p2083[3] = r1992.7
p2083[4] = r32751.0
<3>
p2083[5] = r5389.4
p2083[6] = r2811.0
p2083[7] = r2817.0
p2083[8] = r4648.0
<3> Only if Technology Extension "CHATDTEC" is active.
3 4
[Function diagram] [Function diagram]
Internal status word Signal source
- -
- [8015]
- [8015]
- -
- -
- [8015]
- [2634]
- [2634]
- -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
5 6
fp_2458_01_eng.vsd
07.04.20 V05.02.03
PROFIdrive sampling time
<1>
Inverted
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
CHATDTEC: Chatter Detection
DYNEGMA: Dynamic Energy Management
7 8
Function diagram
- 2458 -
SINAMICS S120
